Saturday, March 23, 2013

Internet Ththering /Revers ththering

The internet (tethering) connection is enabled in your phone. Connect USB cable, go  to Settings->Wireless & Network Settings->Tethering & Portable hotspot and enable USB tethering.



Alternatively you can enable Portable WiFi hotspot (configure in settings) and connect your computer over Wifi network.
HTC Desire with official 2.2 Android



Steps:
1. Rooted the phone with unrevoked3.
Because I can not paste link, Please search relevant threads.
Please notice, select "charge only" when link phone to PC.
Do not unplug phone till unrevoked3 display "done".



2. Set NAT on laptop
Please search relevant threads.
a) Modify Registry Entry:
HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Servic es\Tcpip\Parameters
IPEnableRouter=1



In Command Prompt window, run below command:
b) net stop remoteaccess # Stop the RAS Service
c) netsh routing ip nat install
d) netsh routing ip nat add interface "Local Area Connection" full # This interface have internet link
e) netsh routing ip nat add interface "Wireless Network Connection" private # traffic on this interface will be routed.
f) netsh routing ip nat add interface Internal private
g) net start remoteaccess
h) command "netsh routing ip nat show interface" will output
NAT Internal Configuration
---------------------------
Mode : Private Interface




NAT Local Area Connection Configuration
---------------------------
Mode : Address and Port Translation




NAT Wireless Network Connection Configuration
---------------------------
Mode : Private Interface



3. Enable phone's Hot-Spot with default configuration(DHCP enabled).
Configure laptop connect to phone as AP.
So my laptop's WiFi interface will be DHCPed an ip 192.168.1.157
my phone ip is 192.168.1.1



4. Add route and DNS on phone.
a) "adb shell" in command prompt, then "su".
Now you should login as root.
b) run "ip route add default via 192.168.1.157",
So all phone's traffic will be routed to laptop's WiFi interface.
My LAN interface ip is 192.168.15.100.
Just try "ping 192.168.15.100", It should return successful response.
c) Set DNS server, run "setprop net.dns1 192.168.15.1", Get DNS from laptop with command "ipconfig /all".
Not try ping a existed web site. It should return correct response.



Note:
Windows XP can keep NAT configuration after restart. But you should re-run Step 4 after restart phone's hot-spot.
E-Market and Build-in Browser do work. But GMAIL does not work. It seems Gmail check network connection type
NS703is the best tabet with full option facilities. Also you can connect 3G network with internet and Voip facilitics like SKYPE and facebook.
You can use to this tablet anyware with Analog tv and FM radio .This Tablet has bluetooth connection with connect to Phone and printers.

You can nevigate with gps function with maps and dirctions places where do you going. HD Video functions and 3D game are available for entertains.

4000maH battery is good for games and tv with multimedia. 7" tft screen is the good looking for videos and pictures.






Quick Details

  • Type: Tablet PC
  • Products Status: Stock
  • Screen Size: 7"
  • Processor Manufacture: MTK6577,1.2Ghz-Dual Core, Cortex A9
  • Processor Type: MTK6577,1.2Ghz-Dual Core, Cortex A9
  • Processor Main Frequency: Processor speed 1.2GHZG
  • Hard Drive Capacity: 4GB
  • Memory Capacity: 512MB
  • Touch Screen Type: Capacitive Screen
  • Display resolution: 1024x600
  • Battery Life: 3Hr-4Hr
  • Feature: Bluetooth,Wifi,GPS,3G,Multi Touch ,HDMI,G Sensor ,Camera, Phone Call
  • Operating System: Android 4.0
  • Weight: 315g
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: new sky
  • Model Number: NS703
  • CPU: MTK6577,1.2Ghz-Dual Core, Cortex A9
  • OS: Android 4.0 OS
  • Camera: Front 0.3 MP camera, Rear 2.0 MP camera
  • Wi-Fi: Wireless LAN 802.11 b/g/n
  • 3G: 3G WCDMA embedded, Making phone call
  • Battery: Battery type Lithium-ion 4000mAh
  • Dimensions: 188.38*115.90*12.47mm
  • Color: Black/White
  • Bluetooth /GPS: Support
  • ATV/FM: Support



Specifications


   Processor
MTK6577,1.2Ghz-Dual Core, Cortex A9
Operate system
Android 4.0
Size&*weight
195.5*117.2*9.8mm/ 315 g
Screen
7" TFT LCD 5 points capacitive screen / HD Resolution:1024*600
Battery Charger
Rechargeable Battery: 4000MAH / 5V 0.8A
RAM
512MB DDR3 (Optional : 1GB ram )
Hard Disk
4GB NAND FLASH( Optional: 8GB flash, 16GB flash )
Interface
Mini USB x 1/HDMI x 1 /Stereo Audio out x 1 /Microphone x 1
TF Card slot
TF x 1(maximum: 32GB)
SIM card slot
SIM x 1

3G & 2G
Built-in 3G ( WCDMA850/900/2100 ), 2G ( phone function: GSM850/900/1800/1900 )
Wifi /GPRS/EDGE/HSPDA
Support GPRS / EDGE class12/HSPDA/ WIFI 802.11 a/b/g/n
GPS
Support GPS

ATV
Support ATV

FM
Support FM

Bluetooth
Bluetooth 4.0

Camera
Front camera: 0.3MP, Rear camera: 2.0MP
Video output
Support 1080P video

Game
3D game ,G-Sensor game, Classic game, Touch game
G-sensor
Automatic Four-Direction Rotate screen.
E book format
TXT, EPUB, PDF,WORD,EXCEL, POWERPOINTS
Video format
MPEG-4,H263, H264
Audio format
Mp3,AAC,AAC+,EAAC+,ADPCM

Image format
JPG, JPEG, GIF, BMP, PNG

Software
Support Word, Excel, PPT, TXT,EPUB, PDF ,MSN, Skype
Color Available
Red, black, golden, gray, blue etc

Accessories
Gift box , Instruction Manual , Charger ,USB cable,
Languages
Chinese ,English ,Italian and Spanish.etc
Gift box
240 ×160×70mm


Ampe77 3G+GPS+TV+FM+Blue Tooth






AMPE 77 is the best tabet with full option facilities. Also you can connect 3G network with internet and Voip facilitics like SKYPE and facebook.



Processor QUALCOMM MSM8225 1.2GHz


Operate system Android 4.0



Weight  340g




Screen  7" LCD 5 points capacitive Screen 16:9 / Resolution:800*480
Battery&Charger  Rechargable Li-Polyer Battery: 3000mAH / 5V 2A
RAM  512M DDR3



Hard Disk  4GB NAND FLASH



Interface  1 x DC Jack, 1 x MIC, 1 x Micro USB port, 1 x Earphone Jack
Card slot  1 x TF Card Slot, 1 x SIM 3G Slot

3G  3G WCDMA embedded


Wifi 802.11B/G/N



Camera  2M front camera FF/2.0M Back camera

Video output  Support 720P video



G-sensor  Automatic Four-Direction Rotate screen

Ebook format TXT, EPUB, PDF, WORD, EXCEL, POWERPOINTS
Video format  AVI, RM, RMVB, MKV, WMV, MOV

Audio format  MP3, WMA, MP2, OGG, AAC, M4A, MA4, FLAC, APE, 3GP, WAV
Image format  JPG, JPEG, GIF, BMP, PNG


Software  Support Word, Excel, PPT, PDF, MSN, Skype
Color Available  White




Accessories  Giftbox, Instruction Manual, Charger, USB cable, Earphone
Languages  Chinese, English, Italian and Spanish .etc


Mini ADSL + 3g wireless router



Mini ADSL + 3g wireless router supports USB wireless dongle with inbuilt rj45 port and Battery

How do you share your internet connection with wifi connection to your tablet/phone or laptop. This is the best way to try for that.
This Router supports for 3G internet dongles.Also you can use 3g connection with your laptops and tablets with wifi connection.
You can use the RJ45 connector as a wan or lan port. Also you can conncet to you r SDSL router with RJ45 conncetor can use as a hotsopt.
 Also you can plug the power by usb port or AC/DC charger. It also supports for IEEE802.3X,IEEE802.11b/g/n. speed is Up to 54 Mbps. over 150m. Inferfaces are Micro USB(for DC In)       Ethernet port (Wlan/Lan), Reset button.



Quick Details

  • Type: Wireless
  • Application: Soho
  • Function: Firewall
  • WAN Ports: 1
  • Brand Name: Newsky
  • Model Number: DM8636R-B
  • Place of Origin: Guangdong, China (Mainland)
  • size: 61.5*61.5*21(mm)
  • Wireless Speed: Up to 150 Mbps
  • Color: Blue, White,Pink or Yellow...
  • Ethernet: 1*port
  • battery: 1800MHA
  • adsl: support
  • wifi repeater: support
  • wifi bridge: support
  • usb modem /dongle: support
  • PPPOE dial up: support


Specifications

  1. Inbuilt Battery 3g wireless router support usb wireless dongle
    2.1 Ethernet port (Wlan/Lan)
Feature
Super portable wireless router, as high as 150Mbps
Supports power supply and USB charge
Automatic receipt of IP address with DHCP Server
Supports Virtual Server, Special Application and DMZ host
Provides 64/128-bit WEP encryption security, Supports WPA-PSK/WPA2-PSK
Built-in Firewall, DoS protection function, support WEB management
Automatic 3G/WAN failover
Supports firmware upgrade and remote Web management



Specifications
Standards--IEEE802.3,IEEE802.3U,IEEE802.11b/g/n
Wireless Frequency--2.4G-2.4835GHz
Wireless Speed--Up to 150 Mbps
IP Filtering, Domain Name Filtering, MAC Address Filtering
Interface--1*Micro USB(for DC In)
1*Ethernet port(Wlan /Lan)
1*USB 2.0 for connecting 3G USB modem
1* 3G/WAN switch button
1* Reset button


Internet connection--        Support 3G, PPPoE(DSL and Cable modem), dynamic IP, static IP broadband access
                                          Support Auto Dial, on-Demand Dial,Regular Dial requirements
Wireless Security--           64-bit/128-bit WEP,WPA-PSK/WPA2-PSK
Device Size--                     61.5×61.5×21(mm)
Installation Environment--       Temp.:0~40oC, humidity:10%~90%RH, non-condensing


Accessories
1 x wireless router
1 x charger
1 x Quick Start Guide

Mini cnc router with wifi roaming



How do you share your internet connection with wifi connection to your tablet/phone or laptop. This is the best way to try for that.
You can use the RJ45 connector as a wan or lan port. Also you can conncet to you r SDSL router with RJ45 conncetor can use as a hotsopt.
 Also you can plug the power by usb port or AC/DC charger. It also supports for IEEE802.3X,IEEE802.11b/g/n. speed is Up to 54 Mbps. over 150m. Inferfaces are Micro USB(for DC In)       Ethernet port (Wlan/Lan), Reset button.

Quick Details

  • Type: Wireless
  • Application: Soho
  • Function: Firewall
  • WAN Ports: 1
  • Brand Name: Newsky
  • Model Number: WAP812
  • Place of Origin: Guangdong, China (Mainland)
  • color: Pink/Green
  • Battery: No
  • Wireless Speed: 54 Mbps
  • wifi: IEEE802.11b/g/n
  • Wifi roaming: support
  • Functions: software modify Wi-Fi SSID, Channel and Pass code
  • usb charge: support
  • OS: Windows 2000,XP, XP64, 7, Vista, Visita64
  • Accessory: 1 x wireless AP/ 1 x USB Cable/1 x Quick Start Guide

Packaging & Delivery

Specifications

1.mini cnc router , wireless 802.11n ap router
2.1 Ethernet port(Wlan/Lan)
3.Support ADSL
4.Support wifi roaming

Feature
 1, Super portable wireless AP with MIMO, as high as 54Mbps
 2, Supports power supply and usb charge.
 3, supports IEEE802.3X, and flow control of high speed data transmission
 4, Supports software modify Wifi SSID, Channel and Pass code functions.
 5, Supports Wifi roaming, achieve efficient wireless connections
 6, Supports Windows 2000,XP, XP64, 7, Vista, Visita64 OS
Specifications
 Standards , IEEE802.3X,IEEE802.11b/g/n
Wireless Speed , Up to 54 Mbps
 Interface
           1*Micro USB(for DC In)
           1*Ethernet port(Wlan/Lan)
           1* Reset button

Internet connection
1) Support software modify wireless SSID, Channel and Pass code

2) Support wifi roaming, achieve efficient wireless connection.

 Wireless Security
 IEEE802.3x, and flow control of high speed data transmission
 Device Size
 57×57×18(mm)

 Installation Environment
Temp, 0~40oC,     humidity, 10%~90%RH, non-condensing

 Accessory
             1 x wireless AP
             1 x USB Cable
             1 x Quick Start Guide
